Luminaire for streets and places
GEWISS GWS7227 URBAN [O3] - COMMERCIAL SIDE BRACKETS - 3X16 LED - CYC/PED - BI-POWER SELF-LEARNING - 4000K (CRI 70) - 550mA - IP66 - CLASS II - GRAPHITE GREY
![GEWISS GWS7227 URBAN [O3] - COMMERCIAL SIDE BRACKETS - 3X16 LED - CYC/PED - BI-POWER SELF-LEARNING - 4000K (CRI 70) - 550mA - IP66 - CLASS II - GRAPHITE GREY (img_001)](https://wsu-media.fra1.cdn.digitaloceanspaces.com/prod/sw6/public/media/96/7f/94/1791908974/wsu-lights-gewiss-gws7227_001.webp?ts=1791908974 "GEWISS GWS7227 URBAN [O3] - COMMERCIAL SIDE BRACKETS - 3X16 LED - CYC/PED - BI-POWER SELF-LEARNING - 4000K (CRI 70) - 550mA - IP66 - CLASS II - GRAPHITE GREY (img_001)")
![GEWISS GWS7227 URBAN [O3] - COMMERCIAL SIDE BRACKETS - 3X16 LED - CYC/PED - BI-POWER SELF-LEARNING - 4000K (CRI 70) - 550mA - IP66 - CLASS II - GRAPHITE GREY (img_002)](https://wsu-media.fra1.cdn.digitaloceanspaces.com/prod/sw6/public/media/ba/21/a6/1791908975/wsu-lights-gewiss-gws7227_002.webp?ts=1791908975 "GEWISS GWS7227 URBAN [O3] - COMMERCIAL SIDE BRACKETS - 3X16 LED - CYC/PED - BI-POWER SELF-LEARNING - 4000K (CRI 70) - 550mA - IP66 - CLASS II - GRAPHITE GREY (img_002)")
Art. No.WSL5510007235 P/NGWS7227 EAN8011564802766 BrandGEWISS
€1,107.57 incl. VAT
Availability In stock
Delivery time 7-10 Bussines days
Returns 14-day right of withdrawal for consumers
Warranty Manufacturer warranty depending on the product
Product information
GEWISS URBAN [O3] - COMMERCIAL SIDE BRACKETS - 3X16 LED - CYC/PED - BI-POWER SELF-LEARNING - 4000K (CRI 70) - 550mA - IP66 - CLASS II - GRAPHITE GREY
GEWISS GWS7227
EAN 8011564802766
Description
Strassenleuchte in LED- Technik URBAN, Gehaeuse aus Aluminium-Druckguss, Farbe Graphitgrau oder Aluminium, Leuchtendach nach oben aufklappbar, Die Elektrokomponentenplatte ist werkzeuglos austauschbar, Der Neigungswinkel ist von +10° bis -10° einstellbar, mit Klimamembran, Die Leuchte ist fuer Mastansatz einsetzbar.
Documents & Downloads
Product Attributes
| Anzahl der Module | 3 (3X16 LED) |
|---|---|
| Austauschbarkeit der Lichtquelle | Von Fachleuten |
| Bemessungslichtstrom (lm) | 8060.0 |
| Betriebstemperatur | -25 +35 °C |
| Farb temperatur | 4000 K (CRI>70) |
| Farb- temperatur | 4000.0 K |
| Farbe | Graphitgrau |
| Gewicht (kg) | 10.3 |
| Gruppe | xyz |
| LED Lebensdauer (L80B10) | 100000.0 std |
| LED Lebensdauer (L90B20) | 50000.0 std |
| Nominaler Lichtstrom (lm) | 10230.0 |
| Optik | Fahrräder und Fußgänger - ULOR: 0% |
| Schaltgerät-Austauschbarkeit | Von Fachleuten |
| Spannung | 220-240 V - 50/60 Hz |
| Steuerungssystem | BiPower selbstlernend |
| System leistung | 81.0 W |
| Typ | xyz |
| Überspannungsfestigkeit | Normaler Modus: 8 KV |
| Differenzialmodus | 6 KV |
Technical data
| P/N (Part Number) | GWS7227 |
|---|---|
| EAN | 8011564802766 |
| ETIM | EC000062 |
| Weight | 11.761 kg |
| Weight (Package) | 11.761 kg |
Designations
Street lighting
