Luminaire for streets and places
Performance iN Lighting 303528 LED-Mastleuchte 4000K 11W dimmbar 1-10V runde extrabreite Streuoptik 303528
Art. No.WSL5510007962 P/N303528 EAN8018367615470 BrandPerformance iN Lighting
Adjustable optics No
Built-in battery No
Cable length 0.1 m
Colour consistency (McAdam ellipse) SDCM3
Colour of light White
Colour rendering index CRI 70-79
Colour temperature 4000 K
Connectable conductor cross section 1.5
€429.32 incl. VAT
Availability In stock
Delivery time 2–3 working days
Returns 14-day right of withdrawal for consumers
Warranty Manufacturer warranty depending on the product
Product information
Performance iN Lighting LED-Mastleuchte 4000K 11W dimmbar 1-10V runde extrabreite Streuoptik 303528
Performance iN Lighting 303528
EAN 8018367615470
Description
Leuchte zur Pollermontage für Außenbereiche, zur allgemeinen Beleuchtung, bestehend aus: Gehäuse aus Aluminiumdruckguss mit Polyesterpulverlackierung. Befestigungssatz für Mast mit D= 60-76 mm aus Aluminiumdruckguss mit Polyesterpulver beschichtet als Zubehör erhältlich. Altersbeständige Silikon-Dichtung. Stopfbuchse M25x1,5 für Kabel mit D= 9-14 mm. Externer Stromanschluss über wasserdichte Stecker-Buchsenverbindung QUICK inkl. Kabel. LED-Versionen werden inklusive 230/240 V 50/60 Hz Sicherheitstransformator geliefert. Ausführungen mit dimmbarem EVG, 1-10 V. Zu jeder LED gehört ein elektronisches Sicherheitsgerät (NUD), das diese bei Störungen überbrückt. Außenschrauben aus Edelstahl. SECURE LIGHT DISTRIBUTION-System, das eine einheitliche Verteilung des Lichts auch bei Mängeln einer LED garantiert. Polyester-Pulverbeschichtung, bestehend aus 13 unterschiedlichen Schichten, schützt vor UV-Strahlung. Schutzklasse II.
Documents & Downloads
Product Attributes
Technical data
| P/N (Part Number) | 303528 |
|---|---|
| EAN | 8018367615470 |
| ETIM | EC000062 |
| Weight | 3.16 kg |
| Weight (Package) | 3.59 kg |
Designations
Aussenleuchten Außenbeleuchtung Außenleuchte Außenleuchten Beleuchtung Garten Gartenleuchten LED Außenleuchte LED-Leuchte Park- und Wegeleuchten Poller- und Gartenleuchte Pollerleuchte Stadt- und Parkleuchten Wegeleuchte
Adjustable optics No
Built-in battery No
Cable length 0.1 m
Colour consistency (McAdam ellipse) SDCM3
Colour of light White
Colour rendering index CRI 70-79
Colour temperature 4000 K
Connectable conductor cross section 1.5
Connection type Push-in clamp
Constant light output (CLO) No
Degree of protection (IP) IP65
Diameter 360 mm
Dimming 0-10 V No
Dimming 1-10 V Yes
Dimming DALI No
Dimming DALI-2 No
Dimming DMX No
Dimming DSI No
Dimming LineSwitch No
Dimming RF No
Dimming Sine Wave Reduction No
Dimming Zigbee No
Dimming mains voltage modulation No
Dimming manufacturer's proprietary system No
Dimming phase cut-off No
Dimming phase cut-on No
Dimming programmable No
EF018708 No
EF018709 No
EF018710 No
EF018712 No
EF018714 867
EF018948 No
EF019111 Yes
Energy efficiency class of the light source according to EU regulation 2019/2015 E
Exchangeable control gear Yes
Height/depth 187 mm
Housing colour Anthracite
Housing material Aluminium
Impact strength IK10
Lamp holder Other
Lamp type LED not exchangeable
Lumen maintenance at median useful life of 50,000 h at 25 °C ambient (tq) 92.2 %
Lumen maintenance at median useful life of 100,000 h at 25 °C ambient (tq) 84.8 %
Luminaire efficacy 102 lm/W
Luminaire with limited surface temperature, sign "D“ according to EN 60598-2-24 No
Material cover Plastic, transparent
Max. number of luminaires per miniature circuit breaker B16 (MCB) 30
Max. number of luminaires per miniature circuit breaker C16 (MCB) 51
Max. system power 11 W
Mounting method Post top
Nominal voltage 220 V
Number of poles 4
Operation by Bluetooth No
Protection class II
Rated ambient temperature according to IEC 62722-2-1 -25 °C
Remote control None
Suitable for lamp power 11 W
Suitable for number of light sources 1
Suitable for spigot size 76 mm
Type of connection for sensor/communication module Other
Type of control gear Electronic ballast
Voltage type AC/DC
With connection cable Yes
With control gear Yes
With light regulation program control No
With light sensor No
With light source Yes
With movement sensor No
With presence indicator No
With radio control No
Dimmable Yes
