Downlight/spot/floodlight

Performance iN Lighting 306541 LED-Scheinwerfer 4000K 28W statisch symmetrische Optik mittel 306541

Art. No.WSL5510008735 P/N306541 EAN8021944122926 BrandPerformance iN Lighting

Adjustability Rotatable

Beam angle Medium beam 21-40°

Beam angle adjustable No

Colour consistency (McAdam ellipse) SDCM3

Colour of light White

Colour of light adjustable No

Colour rendering index CRI 80-89

Colour temperature 4000 K

€161.89 incl. VAT

Custom quote for orders of 10 units or more

Availability In stock

Delivery time 2–3 working days

Returns 14-day right of withdrawal for consumers

Warranty Manufacturer warranty depending on the product

Performance iN Lighting LED-Scheinwerfer 4000K 28W statisch symmetrische Optik mittel 306541

Performance iN Lighting 306541

EAN 8021944122926

Description

LED-Scheinwerfer für den Außen- und Innenbereich, bestehend aus: Mit Polymerpulverlack körnig grau lackiertes Aluminiumdruckgussgehäuse nach vorheriger chemischer Oberflächenbehandlung. Diffusor aus gehärtetem Sicherheits-Flachglas. Diffuser ist durch hochtemperaturbeständigen Silikonkleber mit dem Gehäuse fest versiegelt. Hochleistungsreflektoren aus metallisiertem Reinstaluminium 99,99%, hochglänzend, oxidations- und irisierungsfrei. Außenschrauben aus Edelstahl. Glas-Verschlussklemmen aus Edelstahl. Stahlbügel, lackiert mit Polyesterpulverlack nach Kataphorese-Beschichtung. Mit 1 Meter Kabel H05RN-F 3G1 qmm. Die Ausführungen GUELL ZERO KIT werden mit 0,5 m-Arm mit integrierter Anschlussbox geliefert und sind für eine Durchgangsverdrahtung vorgesehen. Mit passivem Infrarot-Bewegungsmelder. LED-Modelle mit 3000 K und 5000 K auf Anfrage lieferbar.

Documents & Downloads

Datasheet

Product Attributes

Technical data

P/N (Part Number)	306541
EAN	8021944122926
ETIM	EC001744
Weight	2.25 kg
Weight (Package)	2.65 kg

Designations

Aussenleuchten Außenbeleuchtung Außenleuchten LED Außenleuchte Scheinwerfer Strahler

Adjustability Rotatable

Beam angle Medium beam 21-40°

Beam angle adjustable No

Colour consistency (McAdam ellipse) SDCM3

Colour of light White

Colour of light adjustable No

Colour rendering index CRI 80-89

Colour temperature 4000 K

Compatible with Amazon Alexa No

Compatible with Apple HomeKit No

Compatible with Casambi No

Compatible with Google Assistant No

Constant light output (CLO) No

Covering of the luminaire with thermally insulating material possible No

Degree of protection (IP) IP66

Degree of protection (IP), rear side Other

Dimming 0-10 V No

Dimming 1-10 V No

Dimming DALI No

Dimming DALI-2 No

Dimming DMX No

Dimming DSI No

Dimming LineSwitch No

Dimming RF No

Dimming Sine Wave Reduction No

Dimming Touch and Dim No

Dimming Zigbee No

Dimming mains voltage modulation No

Dimming manufacturer's proprietary system No

Dimming phase cut-off No

Dimming phase cut-on No

Dimming potentiometer (integrated) No

Dimming programmable No

Dimming with push-button No

EF018713 112.9

EF018714 3162

EF018918 None

EF018921 None

EF019111 Yes

EF019128 20

EFUK0027 No

EFUK0028 No

EFUK0029 No

Energy efficiency class of the light source according to EU regulation 2019/2015 D

Exchangeable control gear No

Filament test according to IEC 60695-2-11 650 °C - 30 s

Height/depth 58 mm

Housing colour Black

Housing material Aluminium

IFTTT support available No

Impact strength IK06

Lamp holder Other

Lamp type LED not exchangeable

Length 231 mm

Light distributor Diffuser lens/optic/panel

Light outlet Direct

Light sharing Symmetric

Lumen maintenance at median useful life of 35,000 h at 25 °C ambient (tq) 95.7 %

Lumen maintenance at median useful life of 50,000 h at 25 °C ambient (tq) 94 %

Lumen maintenance at median useful life of 100,000 h at 25 °C ambient (tq) 88.3 %

Luminaire with limited surface temperature, sign "D“ according to EN 60598-2-24 Yes

Luminous flux adjustable No

Material cover Glass transparent

Max. number of luminaires per miniature circuit breaker B16 (MCB) 20

Max. number of luminaires per miniature circuit breaker C16 (MCB) 57

Max. system power 28 W

Nominal current 700 mA

Nominal voltage 220 V

Number of poles 3

Operation by Bluetooth No

Power factor 0.9

Protection class I

Rated ambient temperature according to IEC 62722-2-1 -20 °C

Reflector High-gloss

Reflector colour Silver

Suitable for built-in mounting No

Suitable for ceiling mounting Yes

Suitable for clamp-mounting No

Suitable for lamp power 28 W

Suitable for light-track mounting No

Suitable for low voltage cable system No

Suitable for number of light sources 1

Suitable for pedestal/floor mounting No

Suitable for surface mounting Yes

Suitable for suspended mounting No

Suitable for traverse mounting No

Suitable for wall mounting Yes

Suitable for workplace according to EN 12464-1 No

Surface brushed No

Surface protection Powder coating

Type of control gear LED operating device current-controlled

Voltage type AC

Width 207 mm

With control gear Yes

With light sensor No

With light source Yes

With movement sensor No

With presence indicator No

Dimmable No
